Ring Lock Scaffolding System for Residential Construction

Pre-galvanized South-east Asia Type Steel Planks without Hooks

South-east Asia Type Plain End Steel Plank is the kind of plank without hook ends, it is a light weight and economical scaffolding plank that made by 1.5mm or 1.2mm thickness of steel plate. The plank shall be fixed to the scaffolding tube or transom by board retainer clamps.

Item NO.:
SP5
Lead Time:
30days
Product Origin:
Guangzhou, China
Shipping Port:
Guangzhou, China
Payment:
T/T, L/C at sight
Min order:
500PCS
Color:
Galvainized Colour; Powder Coated/Painted Blue, Re
Ｍaterial:
Steel

Inquire now

Product Detail

South-east Asia Type Steel Plank, 240mm (9.5") wide, t=1.5mm, without hooks

Code	Size (Metric)	Size (Imperial)	Weight(kg)	Weight(lbs)
SP5.24400	240x4000mm	9.5" x 13'-1 1/2"	19.06	42.03
SP5.24350	240x3500mm	9.5" x 11'-5 13/16"	16.72	36.87
SP5.24300	240x3000mm	9.5" x 9'-10 1/8"	14.38	31.71
SP5.24250	240x2500mm	9.5" x 8'-2 7/16"	12.04	26.55
SP5.24200	240x2000mm	9.5" x 6'-6 3/4"	9.70	21.39
SP5.24150	240x1500mm	9.5" x 4'-11 1/16"	7.37	16.25
SP5.24100	240x1000mm	9.5" x 3'-3 3/8"	5.03	11.09
SP5.24050	240x500mm	9.5" x 1'-7 11/16"	2.69	5.93

* Material: Steel grade Q235. Plank thickness 1.5mm,width 240mm, height 45mm.

* Surface Treatment: Pre-galvanized is recommended, hot dip galvanized , powder coated or painted is also available.

South-east Asia Type Steel Plank, 210mm (8.26") wide, t=1.5mm, without hooks

Code	Size (Metric)	Size (Imperial)	Weight(kg)	Weight(lbs)
SP5.21400	210x4000mm	8.26" x 13'-1 1/2"	17.46	38.50
SP5.21350	210x3500mm	8.26" x 11'-5 13/16"	15.32	33.78
SP5.21300	210x3000mm	8.26" x 9'-10 1/8"	13.17	29.04
SP5.21250	210x2500mm	8.26" x 8'-2 7/16"	11.03	24.32
SP5.21200	210x2000mm	8.26" x 6'-6 3/4"	8.89	19.60
SP5.21150	210x1500mm	8.26" x 4'-11 1/16"	6.74	14.86
SP5.21100	210x1000mm	8.26" x 3'-3 3/8"	4.60	10.14
SP5.21050	210x500mm	8.26" x 1'-7 11/16"	2.45	5.40

* Material: Steel grade Q235. Plank thickness 1.5mm,width 240mm, height 45mm.

* Surface Treatment: Pre-galvanized is recommended, hot dip galvanized , powder coated or painted is also available.
